The oil inspection port is a small glass window the size of a quarter, located on the right-hand side down at the bottom between the foot peg and the front of the fairing. Place the bike on the center stand on level ground to properly check the oil level. The port has high and low level marks. Wipe the glass clean with a rag if the engine is dirty and you can't see the oil inside.
